DC Combiner Box - Non Intelligent without Diode-Model MGV-DCPV2---HA18 Type(500V)

Model:
MGV-DCPV2
DC Combiner Box - Non Intelligent without Diode-Model MGV-DCPV2---HA18 Type(500V)
DC Combiner Box - Non Intelligent without Diode-Model MGV-DCPV2---HA18 Type(500V) DC Combiner Box - Non Intelligent without Diode-Model MGV-DCPV2---HA18 Type(500V) DC Combiner Box - Non Intelligent without Diode-Model MGV-DCPV2---HA18 Type(500V) DC Combiner Box - Non Intelligent without Diode-Model MGV-DCPV2---HA18 Type(500V) DC Combiner Box - Non Intelligent without Diode-Model MGV-DCPV2---HA18 Type(500V)
  • Each channel has a fuse.
  • The shell is made of hot-dip galvanized steel plate, and the cabinet structure is safe and reliable, with sufficient mechanical strength.
  • Ensure that the components are installed without shaking or deformation during operation.
  • Equipped with solar photovoltaic DC high-voltage lightning arrester, both positive and negative electrodes have dual lightning protection function
  • Protection level IP65, with waterproof, dust-proof, rust proof, and salt spray resistance
  • DC withstand voltage value DC500V and DC1000V optional, safe and reliable.
  • Installation and maintenance are simple, convenient, and have a long service life.
  • Except for core components, others can be customized according to user requirements.

Technical Parameter

Model MGV-DCPV8
Sytem DC Voltage 500V
Each Input Current 20A
Number of Input 2 Strings
Max. Output Current 80A
Number of Output 2
Lightning Protection
Test Category II
Nominal Discharge Current 20kA
Max. Discharge Current 40kA
Voltage Protection Level 3.8kV
Max. Voltage 500V
Number of Poles 2P
Structural Characteristics Pluggable module
Protection Level IP65
Output Switch DC circuit breaker (standard)/DC isolator switch (optional)
MC4 Connector Optional
PV DC Fuse Standard
PV DC SPD Standard
Monitor Module No
Diode No
Heat Dissipation Plate No
Shell Material ABS+PC
Installation Mothed Wall-mounted
Working Temperature -25°C '~+55°C
Altitude 2000M
Permissible RH 0-95%, no condensation
