Technical Parameter
| Insulation materials | PPO |
| Material | Copper,Tin plated |
| Applicable current | 30A |
| Rated voltage | 1000V(TUV) 600V(UL) |
| Testing voltage | 6kA(TUV50Hz,1 min) |
| Contact resistance | ＜0.5mΩ |
| Protection grade | IP67 |
| Temperature range | -40℃~+85℃ |
| Flame level | UL94-V0 |
| Security level | || |
| Pin size | φ4mm |
