Technical Parameter
| Metal plug system | φ4mm |
| Rated voltage | 1000V DC(IEC)1 |
| Rated current | 30A |
| Testing voltage | 6kV(50Hz，1 min) |
| Temperature range | -40℃...+90℃(IEC)-40℃...+75℃(UL) |
| Upper temperature limit | +105℃ （IEC） |
| Protection level, plug-in state | IP67 |
| Touch protection, not plugged in state | IP2X |
| Contact impedance of connectors | 0.5mΩ |
| Security level | || |
| Terminal material | Messing,verzinnt Copper Alloy,tin plated |
| Insulating material | PC/PA |
| Locking system | Snap-in |
| Flame level | UL-94-V0 |
| Corrosion test level | IEC 60068-2-52 |
