DC Combiner Box -Intelligent with Diode- Model MGV-DCPV24---Steel Shell(1500V)

• Configure sensors and monitoring display modules to measure and monitor the current of each circuit, enabling remote recording and display of operating conditions without the need for on-site monitoring.
• Added anti reflection diodes to prevent the busbar from flowing back to lower voltage components and damage caused by thermal spots caused by circulating currents between components.
• Each channel has a fuse.
• The shell is made of cold rolled steel , and the cabinet structure is safe and reliable, with sufficient mechanical strength.
• Except for core components, others can be customized according to user requirements.
• Ensure that the components are installed without shaking or deformation during operation.
• Equipped with PV DC high-voltage lightning arrester, both positive and negative electrodes have dual lightning protection function.
• The protection level is IP65, which is waterproof, dust-proof, rust proof, and salt spray proof, meeting the requirements for outdoor installation.
• DC withstand voltage value DC1000V, safe and reliable.
• Installation and maintenance are simple, convenient, and have a long service life.

Technical Parameter
